Media Interface (UCI) Retrofit Kit for A class and B class (W176/W246)


£459.00

Inc. VAT @ 20.00 %  (£76.50)

SKU: MB-MI-W176-RHD
Weight: 0.50 kg

Quantity

Media Interface retrofit kit for the W176 A Class and W246 B class

(Special order part, will take approx 7-10 days to deliver, please tell us your VIN when ordering)

This kit allows you to retrofit the factory-fit Media Interface (also known as UCI) to your A/B vehicle with COMAND or the integrated six disk changer version of the audio-20.

You will also need to purchase the appropriate Media Interface cable set or the cable to connect to the iPhone/3/4/4G cradle if you have an iPhone/3/4/4G comfort phone cradle.

The Media interface provide full iPod (or iPhone music functionality) controllable from the Audio system screen and controls and the steering wheel controls/cluster display, a USB memory device interface, or a 3.5mm aux input, depending which cable you are using. It can also be linked to the iPhone / iPhone3G comfort telephone cradle. (You need to purchase the appropriate cable set depending which one of the above functions you which to use).

It is not suitable for cars with single disk Audio-20 system (i.e no navigation system or integrated six disk changer) or the older DVD based COMAND systems.

Your car's audio software may need updating using Star Diagnosis (dealer computer).
If the NTG2.5 system was factory fitted you will need the dealer to update the car's datacard and code the audio unit to tell it there is a Media Interface present. If the car was not factory fitted with COMAND NTG2.5 you will still need the COMAND/Audio-50 coded using Star diagnosis in developer mode to enable the Media Interface.

Full instructions included. Approx 2 hours to fit.
*
*
*
